Send Email from an EmDash Site: Cloudflare Email Sending & SMTP

An EmDash site sends outbound mail for magic-link sign-in, team invitations, account recovery and comment notifications, plus whatever a plugin needs to deliver (contact forms, for one). Without a configured provider the admin still works, but every flow that sends mail returns 503 EMAIL_NOT_CONFIGURED, and invite links have to be copied by hand. The Cloudflare deploy guide flagged this and deliberately skipped the fix. This is that guide; if you have not deployed yet, that guide and the EmDash CMS tutorial come first.

On Cloudflare Workers there is a native path with no external account and no API key: the send_email binding backed by Cloudflare Email Sending, wired into EmDash with the first-party cloudflareEmail() plugin. It is what runs on emdashhq.com, my EmDash hub for tutorials, themes and plugins, and every command below is one I ran there. There is also a second path, the community emdash-smtp plugin, which is the real answer for anyone on Workers Free or off Cloudflare entirely. This article covers both, then finishes with the contact-forms plugin I built on top of the working setup.

Cloudflare email in three lanes

Cloudflare has several features with “email” in the name that do different jobs. Separating them first saves a confused hour later.

Email Routing receives mail addressed to your domain and forwards it somewhere else. [email protected] is a routing rule: mail sent there lands in a real mailbox behind it (a Gmail account, in my case). Routing is free, unlimited, and available on every plan. Cloudflare does not host mailboxes, and routing alone cannot send anything.

Email Sending to arbitrary recipients is the transactional outbound service, the thing a CMS needs for magic links and invites. It requires Workers Paid ($5/month). Each account gets 3,000 outbound emails per month included in the plan, then $0.35 per 1,000 beyond that. Messages that hard-bounce still count toward quota; messages rejected at the API boundary (bad payload, suppression list) do not.

Sending to verified destination addresses is the exception that works on every plan, Workers Free included. A verified destination address is one you proved you own in the Email Routing settings, the same addresses routing rules forward to. Before any domain is onboarded for Email Sending, a send_email binding can only deliver to those addresses, and only from an address on a routing domain you own. Those sends are always free and never count against quota or daily limits. Good for testing and “send me a copy” flows, useless for a CMS that mails arbitrary users.

How EmDash delivers email

EmDash delegates sending to one active provider plugin. The pipeline is short: a feature (auth, invites, comments, a plugin) produces a message, email hooks can transform or cancel it, and the provider plugin’s email:deliver handler does the send.

• Development. astro dev auto-activates a built-in console provider when nothing else is selected. It sends nothing; it logs each message to the terminal and keeps the last 100 in memory. You can list them at GET /_emdash/api/dev/emails while signed in. Magic links work in dev by copying the URL out of the log.
• Production. The console provider is compiled out. If no provider plugin is active, Settings > Email in the admin shows no provider and sends fail until one is installed, activated and selected.
• On Cloudflare. cloudflareEmail() from @emdash-cms/cloudflare/plugins delivers through the Worker’s send_email binding. Credentials are the binding plus the onboarded domain; there is no token to store or rotate.
• Anywhere else. The community emdash-smtp plugin family covers generic SMTP and hosted providers (SES, Brevo, Mailgun, Postmark, Resend, SendGrid, Zoho and more). Jump to Option 2.

The admin has a Send test email button under Settings > Email that exercises the whole pipeline and surfaces provider errors directly. It is the fastest verification step in this article. The full mechanism is also documented in the EmDash email guide.

Setting up Cloudflare Email Sending on emdashhq.com

Step 1: onboard the sender domain

Sending requires the sender’s domain to be onboarded to Email Service. The dashboard path is Compute > Email Service > Email Sending > Onboard Domain. The CLI does the same job:

npx wrangler email sending enable emdashhq.com

Onboarding creates DNS records automatically:

Verify the state and the exact records Cloudflare expects:

npx wrangler email sending settings emdashhq.com
npx wrangler email sending dns get emdashhq.com

And verify what is actually live in DNS:

dig +short MX cf-bounce.emdashhq.com
dig +short TXT cf-bounce.emdashhq.com
dig +short TXT cf-bounce._domainkey.emdashhq.com
dig +short TXT _dmarc.emdashhq.com

On emdashhq.com all four were already present before the code change. DNS on Cloudflare’s own resolver typically propagates in minutes. Any address on the onboarded domain is an accepted sender; you do not register hello@ or dragos@ individually.

Step 2: add the binding

In wrangler.jsonc, alongside the existing D1, R2 and KV bindings:

"send_email": [
	{
		"name": "EMAIL"
	}
],

The name is what the plugin looks up on the Worker environment. EMAIL is the default; a different name has to be passed to the plugin as its binding option. The full builder API behind the binding (attachments, custom headers, 50-recipient cap) is in the Workers API docs.

Step 3: register the plugin

In astro.config.mjs:

import { cloudflareEmail } from "@emdash-cms/cloudflare/plugins";

emdash({
	// database, storage, objectCache, migrations...
	plugins: [
		siteScriptsPlugin(),
		cloudflareEmail({
			from: { email: "[email protected]", name: "EmDash HQ" },
			replyTo: "[email protected]",
		}),
	],
});

Two options matter:

• from sets the sender. A bare string or { email, name }. The domain must be onboarded or every send fails with E_SENDER_NOT_VERIFIED. A hello@-style address reads better than a personal mailbox on system mail.
• replyTo is where human replies go. With a hello@ or no-reply sender, point it at a mailbox that exists so replies do not get lost. A message-level replyTo overrides this.

There is no wrangler secret step. The binding is the credential: only your Worker can use it. This mirrors the email section of the EmDash Cloudflare deployment doc.

Step 4: deploy

npm run deploy

The site’s deploy script builds, verifies the migration manifest against production D1, uploads the Worker and warms the page cache. A send_email binding needs no provisioning; it attaches to whatever Worker declares it.

If the deploy is gated by pending core migrations (the case right after upgrading emdash), apply them first:

npx wrangler email sending settings emdashhq.com   # optional re-check
npx emdash migrate --status --wrangler-config wrangler.jsonc
npx emdash migrate --wrangler-config wrangler.jsonc
npm run deploy

Step 5: activate and test in the admin

Registration makes the plugin available; it is not active yet.

1. Open https://emdashhq.com/_emdash/admin and go to Extensions. Activate the Cloudflare email plugin.
2. Open Settings > Email. If it is the only provider, EmDash selects it automatically; otherwise pick it.
3. Click Send test email to an address you can check.

A green result means the whole path works: admin, hook pipeline, binding, Email Sending, DNS and the recipient’s filters.

You can also test the binding without involving EmDash at all, which isolates Cloudflare-side problems from CMS-side ones:

npx wrangler email sending send \
	--from "[email protected]" \
	--to "[email protected]" \
	--subject "Email Sending smoke test" \
	--text "If you can read this, the binding and domain are fine."

Step 6 (optional): verify a real flow

Request a magic link for a second admin account, or trigger an invite from the Users page. The mail should arrive signed by cf-bounce._domainkey.emdashhq.com with Reply-To set to the configured address.

Limits and behavior worth knowing

• 50 recipients max per message across to, cc, bcc. EmDash system mail is one recipient at a time, far under the cap.
• 5 MiB total message size including attachments (25 MiB when sending only to verified destination addresses).
• New accounts start with a conservative daily quota that grows automatically with sending history and reputation. A limit-increase form exists for jumping the queue.
• A suppression list blocks addresses that hard-bounced or complained. Sends to suppressed addresses are rejected at the API boundary (and do not bill), or silently dropped for the remaining recipients if Drop suppressed recipients is on.
• Outbound sends appear as dropped in the Email Routing dashboard summary even when they delivered. That view is for inbound. Track sends under Email Service observability instead.
• Delivery is at the mercy of SPF/DKIM/DMARC passing. Onboarding writes all three; if mail lands in spam, check those records first, then sender reputation.
• 30 Email Routing + Email Sending domains max per zone, 200 routing rules per domain, 200 verified destination addresses per account. Full numbers on the limits page and pricing page.

Troubleshooting EmDash email

Symptom, cause, fix. The first two rows are the ones that hit most people.

Option 2: SMTP and hosted providers with emdash-smtp

The binding is not the only way. The community-maintained emdash-smtp plugin family routes EmDash mail through generic SMTP or a hosted provider’s API. It needs EmDash 1.0.1 or later and ships in two packages:

• emdash-smtp is the trusted install. It covers the full provider catalog plus generic SMTP and local sendmail.
• emdash-smtp-marketplace is the sandbox-safe variant for registry/marketplace installs. It runs under sandboxed: and needs a sandboxRunner (sandbox() from @emdash-cms/cloudflare, plus the LOADER binding) in the EmDash config.

Providers

Most providers run over HTTPS, so they work identically on Workers and Node: Amazon SES, Brevo, Elastic Email, Emailit, Mailchimp Transactional, MailerSend, Mailgun, Mailjet, Postmark, Resend, SendGrid, SMTP2GO, SparkPost. Google/Gmail, Microsoft 365 and Zoho Mail use their APIs with OAuth tokens (direct token, or client credential plus refresh token, which the plugin refreshes at send time). Generic SMTP and local sendmail exist only in the trusted package and belong to Node/self-hosted deployments; raw SMTP sockets are not the Workers path.

Setup

npm install emdash-smtp

import { emdashSmtp } from "emdash-smtp";

emdash({
	// database, storage...
	plugins: [emdashSmtp()],
});

Deploy, then in the admin open the plugin’s settings (Plugins > SMTP Providers), pick a provider and paste its credentials. EmDash stores provider credentials as plugin settings in the database, so rotating a key is an admin edit, not a redeploy. Select SMTP under Settings > Email and use Send test email as before.

The free-SMTP option: Brevo

Brevo is the pragmatic pick when cost matters more than staying inside Cloudflare. Its Free plan is free forever, no card, and includes transactional email over SMTP and API at 300 sends per day (roughly 9,000/month if spread evenly). Past the daily cap, transactional mail queues in a retry buffer of up to 1,000 instead of hard-failing. That dwarfs a CMS’s actual need: magic links, invites and comment notices are single-digit emails a day on most sites. Current numbers are on Brevo’s limits page.

Because Brevo goes through its HTTP API in emdash-smtp, it works on Workers Free too. That is the real unlock: a site on the $0 plan cannot use send_email to arbitrary recipients at all, but Brevo’s free tier covers the entire CMS mail load without touching the Workers bill.

Setup outline:

1. Create a Brevo account and add emdashhq.com as a sender domain. Brevo issues its own SPF/DKIM records to add in Cloudflare DNS; they coexist with the Email Sending records since Brevo uses its own DKIM selector and hostname entries.
2. Generate an API key (SMTP & API > API Keys) or an SMTP key (smtp-relay.brevo.com, port 587).
3. Paste it into the plugin’s Brevo provider settings, select SMTP under Settings > Email, send a test.

Put it to work: contact forms that actually send

Once a provider is active, every feature that calls ctx.email.send() rides it. The concrete example on emdashhq.com is @bitdoze.com/emdashhq-contact-forms, a contact-form plugin I published to the EmDash registry. It never talks to an email service itself; it hands messages to whichever provider you configured above, which is how an EmDash plugin should behave. The source lives in the emdashhq.com repo.

What you get:

• A Forms admin page: create and edit forms, manage fields (text, email, tel, url, number, textarea, select, checkbox), reorder, enable/disable.
• A Submissions page: every entry stored with page, IP, country and user-agent; filter by form/status/email result, mark read or archive, resend the notification, copy as CSV.
• An Email log page: every send attempt with status, duration and the provider’s error message verbatim. This doubles as the debugging view for everything in this article; the E_* errors from the troubleshooting table show up here.
• A dashboard widget (unread count, active forms, recent submissions), anti-spam (honeypot, minimum-fill-time trap, per-IP hourly rate limit) and optional retention pruning via the cron.

It is a sandboxed plugin, so it runs in an isolated Worker and needs the same sandbox runner as any marketplace plugin: sandboxRunner: sandbox() plus the LOADER binding and an exported PluginBridge class, per the plugin sandbox docs. That means Workers Paid, the same wall the deploy guide covers. If you took the Brevo path because you are on Workers Free, this plugin is not reachable either way; that is a sandboxing limit, not an email limit.

npm install emdashhq-contact-forms

import { sandbox } from "@emdash-cms/cloudflare";
import contactForms from "emdashhq-contact-forms";

emdash({
	sandboxRunner: sandbox(),
	sandboxed: [
		contactForms, // descriptor object, not a factory call
	],
});

Then wire the page block. EmDash block types live in the site seed, a plugin cannot inject one, so two files ship in the package’s site/ directory to copy:

1. site/block-type.json goes into blockTypes in seed/seed.json, plus "contact_form" in the page field’s validation.allowedTypes (skip that if the field has no allowedTypes, everything is already allowed).
2. site/ContactForm.astro goes into src/components/blocks/, mapped in your block component map as contact_form: ContactForm.

Reseed so the block type reaches the database:

npx emdash seed seed/seed.json --database <dev-db> --no-content --on-conflict=update

In the admin: set a default notification email under Plugins > Contact forms > Settings, create a form with a slug (contact), then add a Contact form block in the page editor and type the slug in. Subject templates accept {form}, {site} and any submitted {field_key}; replies to notification mail go to the visitor’s first email field via replyTo. With no provider configured, submissions still get stored, they just do not get emailed, which is the right failure mode.

Which email path should you pick

• On Workers Paid, low volume, want zero third parties. send_email binding plus cloudflareEmail(). One binding, one plugin call, nothing to rotate.
• On Workers Free, or want delivery tracking, templates, or a bigger free allowance. emdash-smtp with Brevo (free, 300/day) or another HTTP provider.
• High volume. Compare $0.35 per 1,000 over Cloudflare’s included 3,000/month against provider tiers. Dedicated IPs and warmup are a separate procurement question either way.
• Not on Cloudflare. emdash-smtp is the only path; there is no send_email binding on Node.

FAQ: EmDash email

Closing

On Workers Paid, EmDash email is a three-part job: onboard the domain, add send_email to wrangler.jsonc, register cloudflareEmail() and activate it in the admin. No secrets, no third-party account, and 3,000 sends a month before you pay a cent past the $5 plan. On Workers Free or off Cloudflare, emdash-smtp plus Brevo’s free tier covers the same CMS mail load for $0. Either way the proof is the same: install Contact Forms, submit the form, watch the email log.

That is part 5 of the EmDash CMS series: outbound email, both ways.
