How to Self-Host Stirling PDF (Docker, Traefik, Dokploy)

PDF documents are everywhere: contracts, invoices, reports, scanned forms. Manipulating them usually means paying for Acrobat Pro, uploading files to some third-party web tool, or cobbling together command-line utilities that half-work.

Stirling PDF is a self-hosted web application that handles merging, splitting, converting, compressing, OCR, signing, and dozens more PDF operations, all running on your own infrastructure. The project hit V2 in late 2025 with a full React frontend rewrite, stateful undo/redo, desktop apps, a built-in MCP server for AI agents, and Automate/Pipelines for chaining operations. It has over 91,000 GitHub stars and 30M+ downloads. The free self-hosted tier supports up to 5 users with no feature restrictions on operations.

This guide walks through three deployment paths: standalone Docker Compose, Traefik with Dockge, and Dokploy. Each one is copy-pasteable and includes verify steps.

For more useful self-hosted applications, check out our guide on Docker containers for home servers.

What is Stirling PDF?

Stirling PDF is an open-core, self-hosted PDF platform. The free tier gives you full access to 60+ tools, no credits, no watermarks, no artificial limits on the number of operations. It runs as a single Docker container with a Java processing backend, React frontend, and optional integrations for Tesseract OCR, LibreOffice, and PDFium.

Key capabilities of Stirling PDF

How Stirling PDF works

Stirling PDF is an open-source project. View documentation and contribute at the GitHub repository and project website. Full docs are at docs.stirlingpdf.com.

Licensing: free, server, and enterprise

Stirling PDF moved to an open-core model. The breakdown for self-hosters:

For a solo operator or small team, the free tier is all you need. The paid tiers matter when you need SSO or external database support.

Prerequisites

Before deploying Stirling PDF, make sure you have the following:

Image variants:

Infrastructure requirements:

• Server: A VPS or dedicated server. Hetzner VPS or Hostinger VPS work well for this. For on-premise, see mini PCs for home servers.
• Docker Engine: Latest stable release with Docker Compose v2
• Reverse proxy (for HTTPS): Set up a Traefik reverse proxy in Docker or use Caddy. For SSL certificates, follow the Traefik wildcard certificate guide.
• Container management (optional): Dockge for stack management or Dokploy for a full platform
• Domain: A subdomain pointing to your server (e.g., pdf.yourdomain.com)
• Firewall: Port 8080 for standalone, or 443 via reverse proxy

Setup option 1: Docker and Docker Compose (standalone)

This is the simplest path. A single container, no reverse proxy, good for local network access or testing before adding HTTPS.

Step 1: Create project structure

mkdir -p ~/stirling-pdf && cd ~/stirling-pdf

Step 2: Configure Docker Compose

Create a docker-compose.yml file:

services:
  stirling-pdf:
    image: docker.stirlingpdf.com/stirlingtools/stirling-pdf:latest
    container_name: stirling-pdf
    ports:
      - "8080:8080"
    volumes:
      - ./stirling-data/tessdata:/usr/share/tessdata    # OCR language files
      - ./stirling-data/configs:/configs                # settings.yml + H2 DB (back this up!)
      - ./stirling-data/logs:/logs
      - ./stirling-data/customFiles:/customFiles
      - ./stirling-data/pipeline:/pipeline              # Automate / folder-scan configs
    environment:
      - SECURITY_ENABLELOGIN=true                       # login is ON by default
      - SECURITY_INITIALLOGIN_USERNAME=admin            # optional, first boot only
      - SECURITY_INITIALLOGIN_PASSWORD=ChangeMeNow123!  # optional, first boot only
      - SYSTEM_DEFAULTLOCALE=en-US                      # UI language (hyphenated)
      - SYSTEM_GOOGLEVISIBILITY=false                   # block search engine indexing
      - SYSTEM_MAXFILESIZE=500                          # per-file MB (1-999)
      - SPRING_SERVLET_MULTIPART_MAX_FILE_SIZE=2000MB
      - SPRING_SERVLET_MULTIPART_MAX_REQUEST_SIZE=2000MB
    restart: unless-stopped
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost:8080/api/v1/info/status"]
      interval: 30s
      timeout: 10s
      retries: 3
      start_period: 60s

For anonymous access (no login required), set SECURITY_ENABLELOGIN=false and DISABLE_ADDITIONAL_FEATURES=false.

Step 3: Initialize directories and deploy

mkdir -p stirling-data/{tessdata,configs,logs,customFiles,pipeline}
docker compose up -d

Watch the logs to confirm startup:

docker compose logs -f

Look for Started StirlingPDF in the output. If you see unknown configuration key warnings, those are deprecated env vars. Harmless but noisy. Remove them from your compose file.

Step 4: Configure OCR support (optional)

Download Tesseract language packs for OCR:

# English is required. Do not delete eng.traineddata
wget -P stirling-data/tessdata/ https://github.com/tesseract-ocr/tessdata/raw/main/eng.traineddata
wget -P stirling-data/tessdata/ https://github.com/tesseract-ocr/tessdata/raw/main/fra.traineddata
wget -P stirling-data/tessdata/ https://github.com/tesseract-ocr/tessdata/raw/main/deu.traineddata
wget -P stirling-data/tessdata/ https://github.com/tesseract-ocr/tessdata/raw/main/spa.traineddata
wget -P stirling-data/tessdata/ https://github.com/tesseract-ocr/tessdata/raw/main/chi_sim.traineddata

Restart the container after adding language files:

docker compose restart stirling-pdf

Step 5: Verify installation

• Web UI: Navigate to http://localhost:8080
• Health check: curl http://localhost:8080/api/v1/info/status
• API docs: Browse to http://localhost:8080/swagger-ui.html

Common failure: Blank login page after startup. Check container logs with docker compose logs stirling-pdf, ensure volume directories have correct permissions (chmod -R 755 ./stirling-data).

Setup option 2: Traefik and Dockge integration

This setup puts Stirling PDF behind Traefik with automatic HTTPS via Let’s Encrypt. Dockge provides a web interface for managing the compose stack.

Step 1: Verify network configuration

# Check for existing Traefik network
docker network ls | grep traefik-net

# Create if it doesn't exist
docker network create traefik-net

Step 2: Docker Compose configuration

Create a docker-compose.yml with Traefik labels:

services:
  stirling-pdf:
    image: docker.stirlingpdf.com/stirlingtools/stirling-pdf:latest
    container_name: stirling-pdf
    volumes:
      - ./stirling-data/tessdata:/usr/share/tessdata
      - ./stirling-data/configs:/configs
      - ./stirling-data/logs:/logs
      - ./stirling-data/customFiles:/customFiles
      - ./stirling-data/pipeline:/pipeline
    environment:
      - SECURITY_ENABLELOGIN=true
      - SECURITY_INITIALLOGIN_USERNAME=admin
      - SECURITY_INITIALLOGIN_PASSWORD=ChangeMeNow123!
      - SYSTEM_DEFAULTLOCALE=en-US
      - SYSTEM_GOOGLEVISIBILITY=false
      - SYSTEM_MAXFILESIZE=500
      - SYSTEM_ROOTURIPATH=/
      - SPRING_SERVLET_MULTIPART_MAX_FILE_SIZE=2000MB
      - SPRING_SERVLET_MULTIPART_MAX_REQUEST_SIZE=2000MB
    networks:
      - traefik-net
    restart: unless-stopped
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.stirling-pdf.rule=Host(`pdf.yourdomain.com`)"
      - "traefik.http.routers.stirling-pdf.entrypoints=https"
      - "traefik.http.routers.stirling-pdf.tls=true"
      - "traefik.http.routers.stirling-pdf.tls.certresolver=letsencrypt"
      - "traefik.http.services.stirling-pdf.loadbalancer.server.port=8080"
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost:8080/api/v1/info/status"]
      interval: 30s
      timeout: 10s
      retries: 3
      start_period: 60s

networks:
  traefik-net:
    external: true

Note: App branding (name, description, logo) is now configured in-app via Settings → UI, not through environment variables. The old UI_APPNAME and UI_HOMEDESCRIPTION env vars are removed in V2.

Step 3: Deploy via Dockge

1. Access your Dockge dashboard (typically https://dockge.yourdomain.com)
2. Click “New Stack” and name it stirling-pdf
3. Paste the Docker Compose configuration above
4. Update pdf.yourdomain.com in the Traefik labels to your actual domain
5. Click deploy and monitor the logs

Step 4: DNS configuration

Point your subdomain to the server:

Or use a CNAME if your domain already resolves:

Step 5: Verify HTTPS access

After DNS propagates:

• HTTPS: Navigate to https://pdf.yourdomain.com
• SSL certificate: Check that the Let’s Encrypt certificate is valid (click the lock icon in your browser)
• API docs: Browse to https://pdf.yourdomain.com/swagger-ui.html

Setup option 3: Dokploy deployment

Dokploy provides a graphical interface with automated SSL certificate management. This works well if you prefer clicking over typing.

Step 1: Dokploy platform setup

If Dokploy isn’t installed yet, follow the Dokploy installation and configuration guide.

Step 2: Create Stirling PDF project

1. Access your Dokploy dashboard
2. Click “New Project” and name it stirling-pdf
3. Select “Compose” as the application type. Do not use the built-in Stirling PDF template, which may be pinned to an old V1 version

Step 3: Environment variables configuration

Set these environment variables in Dokploy:

Use this in the Dokploy compose configuration:

environment:
  - SECURITY_ENABLELOGIN=${SECURITY_ENABLELOGIN}
  - SECURITY_INITIALLOGIN_USERNAME=${SECURITY_INITIALLOGIN_USERNAME}
  - SECURITY_INITIALLOGIN_PASSWORD=${SECURITY_INITIALLOGIN_PASSWORD}
  - SYSTEM_DEFAULTLOCALE=${SYSTEM_DEFAULTLOCALE}
  - SYSTEM_GOOGLEVISIBILITY=${SYSTEM_GOOGLEVISIBILITY}
  - SYSTEM_MAXFILESIZE=${SYSTEM_MAXFILESIZE}

Step 4: Domain and SSL configuration

1. Navigate to the “Domains” section in your Dokploy project
2. Add your domain: pdf.yourdomain.com
3. Enable SSL/TLS certificate generation
4. Enable automatic certificate renewal
5. Configure HTTP to HTTPS redirection

Step 5: Deploy and monitor

1. Click the “Deploy” button in Dokploy
2. Monitor the deployment logs for errors
3. Verify the health indicator shows green
4. Access your instance and test a PDF operation

Upgrading from V1 to V2

If you’re running an older V1 (0.4x) installation, here’s what to know before upgrading:

docker compose stop stirling-pdf
tar -czf stirling-v1-backup-$(date +%Y%m%d).tar.gz ./stirling-data/configs

Authentication and user management

V2 has login enabled by default.

Default credentials: admin / stirling. Change immediately after first login.

Preset initial credentials (first boot only, via environment variables):

environment:
  - SECURITY_INITIALLOGIN_USERNAME=myadmin
  - SECURITY_INITIALLOGIN_PASSWORD=YourSecurePassword123!

These are only honored on the very first startup. After that, manage users through the admin UI.

Roles: Admin users can manage all settings and users. Regular users get access to PDF operations based on configuration.

API keys: Each user can generate a personal API key from Account → Settings. For automation, set a global API key:

environment:
  - SECURITY_CUSTOMGLOBALAPIKEY=your-long-random-key-here

Login lockout: By default, accounts lock after 5 failed attempts. Configure with:

environment:
  - SECURITY_LOGINATTEMPTCOUNT=5       # set -1 to disable lockout
  - SECURITY_LOGINRESETTIMEMINUTES=120  # lockout duration

SSO: OAuth2 is available on the Server tier ($99/mo). SAML2 requires Enterprise. For a solo operator on the free tier, stick with local accounts.

Anonymous mode (no login at all):

environment:
  - SECURITY_ENABLELOGIN=false
  - DISABLE_ADDITIONAL_FEATURES=false

For production deployments, read our guide on handling secrets in Docker Compose to avoid putting passwords in plain text.

API integration and automation

Stirling PDF exposes a REST API. With login enabled, all API calls require authentication.

API authentication

Get your API key from Account → Settings in the web UI, or set a global key via SECURITY_CUSTOMGLOBALAPIKEY. Pass it as a header:

X-API-KEY: your-api-key

API documentation is available at /swagger-ui.html (also accessible via Settings → API Documentation). The online Scalar registry is at registry.scalar.com/@stirlingpdf.

Example: PDF to images

curl -X POST "https://pdf.yourdomain.com/api/v1/convert/pdf-to-img" \
  -H "X-API-KEY: your-api-key" \
  -H "Content-Type: multipart/form-data" \
  -F "[email protected]" \
  -F "imageFormat=PNG" \
  -F "singleOrMultiple=multiple"

Example: Pipeline (OCR + compress in one call)

The Pipeline/Automate system lets you chain multiple operations in a single API call:

curl -X POST "https://pdf.yourdomain.com/api/v1/pipeline/handleData" \
  -H "X-API-KEY: your-api-key" \
  -F "[email protected]" \
  -F 'json={"name":"OCR-compress","pipeline":[
        {"operation":"/api/v1/misc/ocr-pdf","parameters":{"languages":["eng"],"ocrType":"skip-text"}},
        {"operation":"/api/v1/misc/compress-pdf","parameters":{"optimizeLevel":2}}]}' \
  --output result.pdf

For async processing, add ?async=true to the pipeline URL and poll GET /api/v1/general/job/{id} for status.

n8n workflow integration

Connect Stirling PDF with self-hosted n8n for document processing workflows:

1. Trigger: Email attachment received or file dropped in a watched folder
2. Process: Single pipeline call to OCR + compress + convert
3. Store: Save result to your document management system

A single pipeline call replaces what used to require 5+ chained API nodes. For simple merges without a UI, you can also use pdfunite from the Linux command line.

MCP server for AI agents

Stirling PDF ships with a built-in MCP (Model Context Protocol) server that exposes PDF operations as tools for AI agents. This is useful if you’re building AI workflows that need to process documents.

Enable the MCP server in your compose file:

environment:
  - MCP_ENABLED=true
  - MCP_AUTH_MODE=apikey
  - MCP_ALLOWEDOPERATIONS=stirling_pages,stirling_convert,stirling_misc,stirling_security

Available tool groups: stirling_pages (merge/split/rotate), stirling_convert (format conversions), stirling_misc (compress/OCR/repair), stirling_security (passwords/signatures), stirling_upload, stirling_download.

Claude Desktop configuration: Add this to your claude_desktop_config.json:

{
  "mcpServers": {
    "stirling-pdf": {
      "command": "npx",
      "args": [
        "mcp-remote",
        "https://pdf.yourdomain.com/mcp",
        "--header",
        "X-API-KEY: your-api-key"
      ]
    }
  }
}

Request and response limits default to 10MB. The MCP server does not include an AI engine. It exposes PDF operations as tools that external AI agents can call.

Security best practices and data protection

Stirling PDF has had real security issues. Here’s what you need to know.

SSRF protection

URL-to-PDF conversion is disabled by default (system.enableUrlToPDF: false) because of SSRF risk. If you enable it, SSRF protection is on by default at MEDIUM level (blocks RFC1918, localhost, link-local, and cloud metadata endpoints). Set to MAX for allowlist-only mode:

# In settings.yml
system:
  enableUrlToPDF: true
  urlToPdfProtection: MAX
  allowedDomains:
    - "trusted-domain.com"

Security advisories

Stirling PDF has had several security advisories. Key ones:

Network and access security

• Block search engine indexing: SYSTEM_GOOGLEVISIBILITY=false (already set in the compose examples above)
• Disable unused endpoints: Configure endpoints.toRemove in settings.yml to disable API endpoints you don’t use
• HTTPS only: Always run behind a reverse proxy with TLS. Never expose port 8080 directly to the internet
• Rate limiting: Login-attempt lockout plus fail2ban integration for brute-force protection

Storage and backup

What to back up

Critical data lives in these locations (all under your mounted volumes):

Backup procedure

# Stop the container for a consistent snapshot
docker compose stop stirling-pdf

# Create a compressed backup
tar -czf stirling-backup-$(date +%Y%m%d-%H%M%S).tar.gz \
  -C ./stirling-data configs customFiles tessdata pipeline

# Restart
docker compose start stirling-pdf

Restore procedure

# Stop the container
docker compose stop stirling-pdf

# Extract backup (overwrites current data)
tar -xzf stirling-backup-YYYYMMDD-HHMMSS.tar.gz -C ./stirling-data

# Verify critical files exist
ls -la ./stirling-data/configs/stirling-pdf-DB-*.mv.db
ls -la ./stirling-data/configs/settings.yml

# Restart
docker compose start stirling-pdf

S3 storage (optional)

V2.12+ supports S3-compatible storage for uploads and artifacts. This is useful for multi-server setups or when you want durable storage separate from the container host. Configure in settings.yml under the storage section. The Server and Enterprise tiers also support external PostgreSQL instead of the embedded H2 database.

Performance and resource management

Sizing guidance

V2.12.0 introduced JPDFium for merge and split operations, using up to 99% less memory than the previous engine. V2.14.3 fixed crashes when processing 2GB+ PDFs.

Docker resource limits

Set hard limits to prevent a runaway process from killing your server:

services:
  stirling-pdf:
    # ... other configuration
    deploy:
      resources:
        limits:
          cpus: '2.0'
          memory: 4G
        reservations:
          cpus: '1.0'
          memory: 2G

For memory tuning, set JAVA_TOOL_OPTIONS=-Xmx2g to cap the JVM heap.

Monitoring and health checks

The health endpoint /api/v1/info/status is always accessible without authentication. Use it with Uptime Kuma, Beszel, or any monitoring tool that supports HTTP health checks.

Usage statistics are available at /api/v1/info/requests/all (total requests) and /api/v1/info/requests/unique (unique requests).

Troubleshooting common issues

environment:
  - SERVER_JETTY_MAX_HTTP_REQUEST_HEADER_SIZE=16384

Maintenance and updates

Update procedure

cd ~/stirling-pdf

# Pull the latest image
docker compose pull

# Recreate the container
docker compose up -d

# Clean up old images
docker image prune -f

Version pinning: In production, consider pinning to a specific tag (e.g., docker.stirlingpdf.com/stirlingtools/stirling-pdf:v2.14.3) instead of :latest. This prevents surprise breakage from automatic updates. When you’re ready to upgrade, update the tag and run docker compose pull && docker compose up -d.

Back up before major upgrades. The v2.12.0 release itself recommended backing up before upgrading. Releases come out 2-4 times per week and include security fixes — subscribe to the GitHub releases feed to stay informed.

For automated container updates, consider auto-updating Docker containers with Tugtainer.

Maintenance schedule

Conclusion

Self-hosting Stirling PDF gives you a private, capable PDF processing platform that runs on your own infrastructure. The V2 rewrite brought a modern React frontend, memory-efficient PDFium processing, a built-in MCP server for AI agent integration, and Automate/Pipelines for chaining operations.

Start with Option 1 (standalone Docker Compose) to get running in 5 minutes. Add Traefik when you need HTTPS. Use Dokploy if you want a GUI. The desktop apps are a bonus for local processing on your own machines.

Explore our guides on Docker container orchestration with Dockge, Traefik reverse proxy configuration, and Dokploy platform management.
