Add Voice Cloning TTS to Mastra with Fish Audio

I already have a Mastra assistant that searches the web, reads files, runs shell commands, and remembers context. I also added an image agent with Kie.ai for covers and thumbnails.

What was still missing for video was voice. Stock TTS sounds like every other AI demo. I wanted narration in my voice — cloned once, reused forever — with emotion control so technical explainers do not sound flat.

So I wired Fish Audio into Mastra as one tool: fish_tts. The agent writes the script (with [emotion] tags), calls the tool, and gets a .wav on disk. That file drops straight into HyperFrames for YouTube and Shorts.

This guide covers the full path: clone a voice, build the tool, register it on an agent, and use emotion tags for delivery. Same pattern works in the mastra-assistant repo or any existing Mastra app.

If you have not used Fish Audio yet, start with the Fish Audio review or the 2-minute clone walkthrough. Comparing vendors? See Fish Audio vs ElevenLabs and Fish Audio vs MiniMax.

Try Fish Audio Free Build a Mastra Agent First

Why Fish Audio for agent TTS

Most TTS APIs give you stock voices. Fine for prototypes. Bad when the product is your channel and viewers expect your voice.

Feature	What you get
Voice cloning	~15 seconds of sample audio → a reusable voice model ID
S2.1 Pro quality	Production TTS with natural prosody
Emotion control	[happy], [excited], [calm], free-form cues like [warm and friendly]
Simple HTTP API	POST https://api.fish.audio/v1/tts → raw audio bytes (no long poll job)
Formats	wav, mp3, opus — wav works cleanly with video pipelines
Dev model	s2.1-pro-free — same quality as paid S2.1 Pro for development (fair-use; check current terms)
Languages	80+ with automatic language detection

Why this beats local Kokoro / OpenAI TTS / ElevenLabs for my agent setup:

• Clone once, reuse forever — reference_id points at your voice model
• Sync response — no create-task / poll loop like many image APIs
• Emotion in the text — the agent writes tags in the script; no separate style field to forget
• One clear tool — inputs are obvious, output is a binary file on disk

I use it as the only TTS path for the video-creator agent. Skills that default to HeyGen, ElevenLabs, or Kokoro get overridden: always fish_tts.

What you will build

The tool can:

• Generate speech from text using your cloned voice
• Apply speed, volume, temperature, and latency settings
• Embed emotion / pause markers ([confident], [break], …)
• Save wav / mp3 / opus under a path the agent chooses
• Return success, path, and bytes written (or a clear error)

Prerequisites

• A working Mastra project (see Build Your Own AI Agent with Mastra)
• Node.js 22+ or Bun (this repo defaults to Bun)
• An LLM API key for the agent brain (OpenRouter, OpenCode Go, etc.)
• A Fish Audio account

Optional: HyperFrames (or any video stack) if you want full voiceover → transcript → caption pipelines. TTS works without video — you only need a place to save the file.

Architecture

User (Studio chat / workflow)
    │
    ▼
agent  (LLM + instructions)
    │
    └─ fish_tts  ──► POST api.fish.audio/v1/tts
                          │
                          ▼
                     workspace/.../narration.wav
                          │
                          ▼ (optional)
                     hyperframes transcribe → transcript.json
                     composition <audio class="clip">

The LLM never holds the API key. It only chooses tools. Auth, path safety, and binary download stay in TypeScript where you can test them.

Step 1: Create an API key and clone your voice

1. Sign up at Fish Audio
2. Create an API key in the dashboard
3. Clone a voice: upload ~15 seconds of clean speech (one speaker, little noise)
4. Copy the resulting voice model ID — this is reference_id in the API

Need screenshots and recording tips? Follow Clone your voice with Fish Audio in 2 minutes.

Add to .env:

FISH_API_KEY=your-fish-audio-key
FISH_VOICE_ID=your-cloned-voice-model-id
# TTS model default for fish_tts (override per call with model: still works)
FISH_TTS_MODEL=s2.1-pro-free

Env var	Role
FISH_API_KEY	Bearer token for api.fish.audio
FISH_VOICE_ID	Default cloned voice model ID (reference_id)
FISH_TTS_MODEL	Default TTS model string (DEFAULT_MODEL in the tool). Use s2.1-pro-free while developing; switch to s2.1-pro for production SLA

Never put the key in frontend code or commit it to git.

Voice cloning tips

• Use a quiet room and natural pacing
• Prefer a continuous monologue over short clips stitched together
• Match the language you will narrate most often
• Re-clone if the source was compressed or noisy — bad clone means bad every generation

Clone Your Voice Free

Step 2: Fish Audio client basics

Fish Audio TTS is a single POST. Success returns raw audio bytes, not JSON.

Auth and endpoint

POST https://api.fish.audio/v1/tts
Authorization: Bearer YOUR_API_KEY
Content-Type: application/json
model: s2.1-pro-free   # or s2.1-pro | s2-pro | s1

Request body (fields we use)

{
  "text": "[confident] Docker makes deployment simple. [break] [excited] This tool makes it even easier.",
  "reference_id": "YOUR_VOICE_MODEL_ID",
  "format": "wav",
  "prosody": {
    "speed": 1.0,
    "volume": 0,
    "normalize_loudness": true
  },
  "temperature": 0.7,
  "top_p": 0.7,
  "chunk_length": 300,
  "normalize": true,
  "latency": "normal",
  "max_new_tokens": 1024,
  "repetition_penalty": 1.2,
  "condition_on_previous_chunks": true
}

Field	Role
text	Script + [emotion] markers (S2 / S2.1). Max ~10k chars in our tool.
reference_id	Cloned voice model ID
format	wav | mp3 | opus
prosody.speed	0.5–2.0 (1.0 = natural for explainers)
prosody.volume	dB offset (−20…20)
temperature	Higher = more expressive variation
latency	normal (quality) | balanced | low

On success: write Buffer.from(await res.arrayBuffer()) to disk. On error: parse JSON message when present.

Models

Model id	Notes
s2.1-pro-free	Same quality as S2.1 Pro for dev / fair use — good default while exploring
s2.1-pro	Production S2.1 Pro with SLA
s2-pro	Previous S2 generation; still uses [bracket] emotions
s1	Legacy; emotions use (parentheses) not brackets

Emotion docs: docs.fish.audio — Emotion Control.

Step 3: Mastra fish_tts tool

Create src/mastra/tools/fish-audio-tts.ts. Tools are createTool + Zod. The description field is the model-facing API docs — write it carefully so the agent embeds emotion tags correctly.

import { createTool } from "@mastra/core/tools";
import { z } from "zod";
import { resolve, isAbsolute, dirname } from "node:path";
import { mkdirSync, writeFileSync } from "node:fs";

const FISH_API_BASE = "https://api.fish.audio";
const DEFAULT_VOICE_ID = process.env.FISH_VOICE_ID ?? "";
// Default TTS model from env (s2.1-pro-free for dev; s2.1-pro for production SLA)
const DEFAULT_MODEL = process.env.FISH_TTS_MODEL ?? "s2.1-pro-free";
// Resolve relative output paths against your workspace root.
const WORKSPACE_PATH = process.env.WORKSPACE_PATH ?? `${process.cwd()}/workspace`;

function getApiKey(): string {
  const apiKey = process.env.FISH_API_KEY;
  if (!apiKey) {
    throw new Error(
      "FISH_API_KEY is not set. Add it to .env to enable Fish Audio TTS.",
    );
  }
  return apiKey;
}

export function createFishTts(basePath: string = WORKSPACE_PATH) {
  return createTool({
    id: "fish_tts",
    description: `Generate narration audio from text using Fish Audio S2.1 Pro TTS with a cloned voice.

EMOTION CONTROL (S2.1 Pro): Add emotion/style cues in [square brackets] directly in the text. Examples:
  [happy] What a great tool!
  [excited] And the best part? It's free!
  [calm] Let me walk you through the setup.
  [confident] This is the best option on the market.
  [curious] But what about performance?
  [sarcastic] Oh sure, because THAT always works.
  [whispering] Here's a secret most people miss.
  [laughing] Ha ha, yeah, I tried that too.
  [sighing] Another config file... sigh.

Combine emotions: [sad][whispering] for a quiet sad tone, [excited][laughing] for joyful energy.
Use [break] for a short pause, [long-break] for a longer pause.
Place emotion cues at the START of the sentence they should affect.
Natural language descriptions also work: [warm and friendly], [slightly annoyed], [very energetic].

For technical narration, [confident] or [calm] works best as the base tone. Use [excited] sparingly for highlights. Avoid [happy] for informational content — it sounds salesy.`,
    inputSchema: z.object({
      text: z
        .string()
        .max(10000)
        .describe(
          "Narration text. Supports [emotion] tags like [happy], [excited], [calm], [whispering], [break]. Place cues at sentence starts.",
        ),
      outputPath: z
        .string()
        .describe(
          "Path to save the audio. Relative paths resolve against the workspace. Extension must match format (.wav, .mp3, .opus).",
        ),
      speed: z
        .number()
        .min(0.5)
        .max(2)
        .optional()
        .describe("Speech speed. 1.0 = normal. Default 1.0."),
      volume: z
        .number()
        .min(-20)
        .max(20)
        .optional()
        .describe("Volume in dB. 0 = no change. Default 0."),
      voiceId: z
        .string()
        .optional()
        .describe("Fish Audio voice model ID. Defaults to FISH_VOICE_ID."),
      model: z
        .enum(["s2.1-pro-free", "s2.1-pro", "s2-pro", "s1"])
        .optional()
        .describe(
          "TTS model. Defaults to FISH_TTS_MODEL env (or s2.1-pro-free). Use s2.1-pro for production SLA.",
        ),
      format: z
        .enum(["wav", "mp3", "opus"])
        .optional()
        .describe("Output format. Default wav (good for video pipelines)."),
      temperature: z
        .number()
        .min(0)
        .max(1)
        .optional()
        .describe("Expressiveness. Higher = more varied. Default 0.7."),
      latency: z
        .enum(["normal", "balanced", "low"])
        .optional()
        .describe("normal = best quality (default). low = fastest."),
    }),
    outputSchema: z.object({
      success: z.boolean(),
      path: z.string().optional(),
      bytesWritten: z.number().optional(),
      format: z.string().optional(),
      error: z.string().optional(),
    }),
    execute: async (input) => {
      const apiKey = getApiKey();
      const format = input.format ?? "wav";
      const model = input.model ?? DEFAULT_MODEL;
      const voiceId = input.voiceId ?? DEFAULT_VOICE_ID;
      const speed = input.speed ?? 1.0;
      const volume = input.volume ?? 0;
      const temperature = input.temperature ?? 0.7;
      const latency = input.latency ?? "normal";

      if (!voiceId) {
        return {
          success: false,
          error:
            "No voice ID. Set FISH_VOICE_ID or pass voiceId. Clone a voice at Fish Audio first.",
        };
      }

      const absPath = isAbsolute(input.outputPath)
        ? input.outputPath
        : resolve(basePath, input.outputPath);

      try {
        mkdirSync(dirname(absPath), { recursive: true });
      } catch {
        // Directory may already exist
      }

      const body = {
        text: input.text,
        reference_id: voiceId,
        format,
        prosody: {
          speed,
          volume,
          normalize_loudness: true,
        },
        temperature,
        top_p: 0.7,
        chunk_length: 300,
        normalize: true,
        latency,
        max_new_tokens: 1024,
        repetition_penalty: 1.2,
        condition_on_previous_chunks: true,
      };

      try {
        const res = await fetch(`${FISH_API_BASE}/v1/tts`, {
          method: "POST",
          headers: {
            Authorization: `Bearer ${apiKey}`,
            "Content-Type": "application/json",
            model,
          },
          body: JSON.stringify(body),
        });

        if (!res.ok) {
          let errMsg = `Fish Audio TTS failed (HTTP ${res.status})`;
          try {
            const errData = await res.json();
            errMsg = errData?.message || errMsg;
          } catch {
            // not JSON
          }
          return { success: false, error: errMsg };
        }

        const audioBuffer = Buffer.from(await res.arrayBuffer());
        if (audioBuffer.length === 0) {
          return {
            success: false,
            error: "Fish Audio TTS returned empty audio data.",
          };
        }

        writeFileSync(absPath, audioBuffer);

        return {
          success: true,
          path: absPath,
          bytesWritten: audioBuffer.length,
          format,
        };
      } catch (error) {
        return {
          success: false,
          error: `Fish Audio TTS failed: ${
            error instanceof Error ? error.message : "Unknown error"
          }`,
        };
      }
    },
  });
}

// Default instance against workspace root
export const fishTts = createFishTts();

Factory with a custom base path

Video projects often live under a dedicated directory (for example workspace/hyperframes/). Use the factory so relative paths resolve correctly:

import { createFishTts } from "../tools/fish-audio-tts";

// Paths like "my-video/assets/narration.wav" land under hyperframes/
const fishTts = createFishTts("/absolute/path/to/workspace/hyperframes");

That is how the video-creator agent is wired: one tool instance scoped to the HyperFrames workspace, not the whole monorepo.

Step 4: Define a voice-aware agent

You can attach fish_tts to any agent. Minimal example — a focused voice agent for testing:

import { Agent } from "@mastra/core/agent";
import { fishTts } from "../tools/fish-audio-tts";

const AGENT_MODEL =
  process.env.AGENT_MODEL ?? "google/gemini-2.5-flash";

export const voiceAgent = new Agent({
  id: "voice-agent",
  name: "Voice Agent",
  instructions: () => {
    const iso = new Date().toISOString().split("T")[0];
    return `TODAY IS ${iso}.

You generate voiceover with the fish_tts tool using the user's cloned voice.

## Rules
- Always use fish_tts for audio. Never invent a local file path without calling the tool.
- Write narration WITH [emotion] tags. Base technical tone: [confident] or [calm].
- Highlights: [excited]. Problems: [frustrated]. Pauses: [break] or [long-break].
- Place emotion tags at the START of the sentence they affect. One primary emotion per sentence.
- Default speed 1.0. Default format wav.
- After success, report the local path and bytes written.
- If FISH_API_KEY or FISH_VOICE_ID is missing, say so clearly.
- TTS model defaults to FISH_TTS_MODEL (usually s2.1-pro-free); only pass model when you need a different one.`;
  },
  model: AGENT_MODEL,
  tools: {
    fishTts,
  },
  defaultOptions: { maxSteps: 10 },
});

Video agent instructions (the real use case)

In a full video pipeline, voiceover is one step among research → design → script → TTS → build → render. The important instruction pattern:

4b. VOICEOVER — Generate narration BEFORE building so the timeline can be sized to it.
- Finalize the narration script from research.
- Call fish_tts with text + output path like <project>/assets/narration.wav
- Keep speed at 1.0
- Embed emotion tags in the script, e.g.:
  "[confident] Docker makes deployment simple. [break] [excited] But this new tool? It makes Docker look complicated."
- After TTS: transcribe for word-level timestamps (e.g. hyperframes transcribe)
- Drop audio into the composition as <audio class="clip">

And force a single TTS provider so the model does not wander:

TTS: Always use fish_tts (cloned user voice).
Do NOT use Kokoro, hyperframes tts, HeyGen, or ElevenLabs for narration.

Register the agent

In src/mastra/index.ts:

import { Mastra } from "@mastra/core/mastra";
import { assistant } from "./agents/assistant";
import { voiceAgent } from "./agents/voice-agent";
// or: import { videoCreator } from "./agents/video-creator";

export const mastra = new Mastra({
  agents: {
    assistant,
    voiceAgent,
    // videoCreator,
  },
  // storage, logger, server — same as your existing app
});

If you use domain flags (lighter deploys), gate video/voice behind env:

// ENABLE_VIDEO=false to skip
if (process.env.ENABLE_VIDEO !== "false") {
  agents.videoCreator = videoCreator;
}

Step 5: Run and try it

# .env must include:
# FISH_API_KEY=...
# FISH_VOICE_ID=...
# FISH_TTS_MODEL=s2.1-pro-free   # or s2.1-pro for production
# OPENROUTER_API_KEY=...   (or your LLM provider)
# AGENT_MODEL=google/gemini-2.5-flash

bun run dev
# or: npm run dev

Open Studio at http://localhost:4111, select Voice Agent (or Video Creator), and try:

Generate a 20-second voiceover for a blog intro about Mastra + Fish Audio.
Save as voice/demo-narration.wav.
Use [confident] for the base tone and [excited] once when mentioning voice cloning.

What you should see in traces:

1. The agent drafts a short script with emotion tags
2. fish_tts with text, outputPath, speed: 1.0
3. Success with a local path and bytesWritten
4. File on disk under your workspace

Sample narration with emotions

[confident] If you already have a Mastra agent for research and coding, voice is the next unlock.
[break]
[calm] Clone your voice on Fish Audio in about fifteen seconds, then expose a single fish_tts tool.
[excited] From there, every video can sound like you — without sitting in front of a mic again.

After TTS (video pipeline)

For HyperFrames-style caption timing:

npx hyperframes transcribe assets/narration.wav -d .
# → transcript.json with word-level timestamps

Use those timestamps for scene cuts and word-synced captions. Do not invent timings.

Emotion cheat sheet (S2 / S2.1)

Square brackets. Place at the start of the sentence. Free-form descriptions work ([warm and friendly]).

Use case	Tags
Technical base tone	[confident], [calm]
Feature highlight	[excited]
Surprise / reveal	[surprised]
Pain point	[frustrated]
Aside / humor	[sarcastic], [laughing]
Build-up	[curious]
Quiet tip	[whispering]
Pause	[break], [long-break]
Combined	[excited][laughing] We won!

Full list: Fish Audio emotion guide.

Where this fits with image + research agents

Same Mastra app, specialized tools:

Agent	Job	Backend
Assistant	Research, files, shell	TinyFish, workspace
Image agent	Covers / thumbnails	Kie.ai
Video / voice	Narration + compositions	Fish Audio + HyperFrames

Pattern that works:

1. Research topic (assistant tools)
2. Generate cover (image agent)
3. Script + fish_tts + render (video agent / pipeline)

Keep tools thin and auth server-side. The LLM picks tools; TypeScript owns HTTP and files.

Multi-phase video pipeline

If a single agent hits context limits, split phases (research → assets → design → script → voiceover → build → validate → render). Only the voiceover phase needs fish_tts. Later phases read assets/narration.wav and transcript.json from disk — no need to regenerate audio unless the script changes.

Production tips

1. Clone quality is everything. Garbage sample → garbage every video. Re-record if it sounds off.
2. Default speed 1.0. Agents love to crank speed; for explainers, natural pace keeps people listening.
3. Write emotion tags into the script. Do not generate dry text then hope the model adds tags later.
4. Persist files in your workspace. The tool already writes to disk — treat that path as source of truth for the next pipeline step.
5. One voice ID per brand. Store FISH_VOICE_ID in env; allow voiceId override only when you truly multi-voice.
6. Set FISH_TTS_MODEL in env (DEFAULT_MODEL in code). Dev: s2.1-pro-free. Production SLA: s2.1-pro. Agents can still pass model per call. Check models overview for current free-tier policy.
7. Keep secrets server-side. FISH_API_KEY only in .env / host secrets.
8. Cap text length. Long scripts: split into sections, generate multiple files, concat with ffmpeg if needed.
9. Separate agent from coding assistant. Voice + video burns steps. A dedicated agent keeps the research assistant focused.

Troubleshooting

401 / auth errors

Missing or wrong Authorization: Bearer …. Confirm FISH_API_KEY is loaded by the process (Bun loads .env automatically; Node may need extra config).

Empty audio / zero bytes

Rare empty body — treat as failure and retry. Check the Fish dashboard / status if it keeps happening.

Wrong voice / generic voice

reference_id wrong or empty. Confirm FISH_VOICE_ID matches the clone in the Fish dashboard. Pass voiceId explicitly once to verify.

Emotions ignored

Using S1 syntax (happy) with S2.1 models — switch to [happy]. Tags placed mid-sentence far from the words they should color — move to sentence start. Over-tagging — simplify to one cue per sentence.

Unnatural delivery

Lower temperature toward 0.5 for consistency, or raise slightly for variety. Keep speed at 1.0. Space emotional changes.

Path not found / wrong directory

Relative paths resolve against the tool’s basePath. Video agents should use createFishTts(HYPERFRAMES_PATH) so project/assets/narration.wav lands next to the composition.

HTTP 429 / rate limits

Back off and retry. Batch voiceovers with a short delay in workflows.

Agent uses Kokoro / another TTS

Instructions not strong enough. Explicitly ban alternate TTS tools and list fish_tts as the only allowed voiceover path.

Related Fish Audio and Mastra guides

• Fish Audio review 2026 — pricing, free API, what is good and what is not
• Clone your voice with Fish Audio — 2-minute walkthrough with screenshots
• Fish Audio vs ElevenLabs — side-by-side quality, cloning, and yearly cost
• Fish Audio vs MiniMax — English vs Chinese quality, pricing, free API
• Build a Mastra agent — files, web, browser, memory
• Mastra image agent with Kie.ai — covers and thumbnails
• Mastra vs Eve — framework choice for TypeScript agents

Once voice works, the same pattern extends to full autonomous video: research → storyboard → fish_tts → HTML composition → render. I keep that as a dedicated video agent (or multi-phase workflow) so step budgets and instructions stay clean.

Get started with Fish Audio Mastra Assistant Guide
